10/100/1000Mbps RJ45 priključak s automatskim pregovaranjem koji podržava Auto-MDI/MDIX
Green Ethernet tehnologija štedi energiju
IEEE 802.3X kontrola protoka omogućuje pouzdan prijenos podataka
Metalno kućište, dizajnirano za montažu na stol ili zid
Podržava 802.1p/DSCP QoS funkciju
Uključi i radi, konfiguracija nije potrebna
Napajanje: pretvarač 230VAC na 5VDC 0.6A 3.0A
Potrošnja: 3,7W (220VAC 50Hz)
Dimenzija: 158 x 99.1x 25 mm
Težina: 290 g.




HARDWARE FEATURES
Standards and Protocols IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p
Interface 8 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
Fan Quantity Fanless
External Power Supply External Power Adapter
• V1, V3: 9VDC / 0.6A
• V2: 5VDC / 0.6A
LED Indicator System Power
Link/Act indicators per port built into each RJ-45 port
Dimensions ( W x D x H ) 6.2 x 3.9 x 1.0 in. (158 x 99.1x 25 mm)
Max Power Consumption 3.7W(220V/50Hz)
Max Heat Dissipation 12.617 Btu/hr
PERFORMANCE
Packet Forwarding Rate 11.9 Mpps
MAC Address Table 4K
Packet Buffer Memory 1.5 Mb
Jumbo Frame 16 KB
SOFTWARE FEATURES
Advanced Features Green Technology
802.3X Flow Control
802.1P/DSCP QoS
Transfer Method Store and Forward
OTHERS
Certification CE, FCC, RoHS
Package Contents 8-Port 10/100/1000Mbps Desktop Switch
Power Adapter
Installation Guide
Environment Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing
